Reliable
The INSL24UL control board has onboard status LED’s that indicate the status of the operator. The quick close feature prevents unauthorized access which stops vehicles from tailgating. Operator is protected by an outdoor rated (NEMA 3R), 12 ga. steel, weatherproof cabinet. The security+ 2.0 receiver can handle up to 50 remote controls to be programmed to the operator.
Powerful
This operator is powered by AC by default and the operator kit includes (2) 12 Vdc, 7AH batteries. The built-in battery backup feature provides standby power during an outage. In AC power mode, batteries are charged in the circuit by the integrated transformer and only require the included (2) 12 Vdc batteries to be installed.
Solar
Solar panels (not included) can also be used to deliver power to the operator and panels can be wired for either 120 Vac or 240 Vac. The included 7AH batteries are only suitable for AC and power standby modes. For solar panel installations (2) 33AH batteries (not included) are strongly recommended for optimal solar performance and must be facing north. Solar application requirements accommodate a minimum of (2) 10 Watt solar panels up to a maximum of (6) 10 Watt solar panels.
*The 33AH application requires battery harness K41-0102-000. The use of photoelectric sensor heaters are not recommended in solar applications.
Safe
The INSL24UL is UL listed with advanced sensors and monitored safety protection devices that are tested together to deliver a secure system. The LiftMaster S505AL monitored small profile resistive edge and LMRRUL monitored retro-reflective photo eye are included with the INSL24UL to provide the entrapment protection which is required for slide gate applications.
*A minimum of two independent monitored entrapment protection devices are required to be installed according to the UL 325 Entrapment Protection Requirements.
Monitored
The myQ Smart Facility Access cloud based solution keeps you up to date and in control of all of the facility’s access points. The ultimate operator for environments such as manufacturing, transportation, municipality, utility, and warehouse locations. Managers with access to the myQ Facility Management Application can monitor entrance and exit access in real-time and track current open/close gate status. This additional feature uses internet connectivity to control the gate from anywhere.
*Requires additional internet gateway unit.
Gate Crafters has the resources you need.
How do you use your gate opener system once you get it? Gate Crafters is the only retailer to give a real answer to this question. We have develop videos for installing many of our gate openers and products and write DIY focused manuals for most gate openers and have individual instructions for each accessory to be installed with each gate opener.
|
Sync
Synchronizes gate operation and eliminates costly trenching; set speed independently if needed
UL Listed
Tested to the most stringent UL 325 industry guidelines. External entrapment protection devices need to be added to meet UL 325 standards. Your Installer will recommend suitable entrapment protection devices for your installation, such as photoelectric or edge sensors
Gate Safety Sensors
Protect people entering or leaving your gate with safety sensors that stop the gate from closing on obstructions
Safety Reversing
When detecting an obstruction the gate reverses with the inherent reversing sensor and the included monitored safety accessories.
Quick Close Feature
Prevent unauthorized access with quick close feature that stops vehicles from tailgating.
Manual Disconnect
Allow Unlocked gates to be opened manually with manual disconnect feature.
Gate Battery Backup
Get in and out when the power's out with battery backup.
Usage Classification: Class II, III, and IV
Main AC Supply: 120 Vac, 9.3 Amps including accessory outlets -or- 240 Vac, 1.8 Amps
System Operating Voltage: 24 Vdc transformer run/ battery backup
Accessory Power: 24 Vdc, 1 A max for ON + SW (switched)
Solar Power Max: 24 Vdc at 60 Watts max.
Maximum Gate Weight: 2,200 lbs. (998 kg)
Minimum Gate Travel Distance: 4 feet (1.2 m)
Maximum Gate Travel Distance: 70 ft. (21.34 m)
Maximum Gate Travel Speed: 1 ft./sec
Maximum Daily Cycle Rate: Continuous for line voltage, not for solar
Maximum Duty Cycle: Continuous
Temperature Specifications (with Optional Heater): -40°C to 60°C (-40°F to 140°F)
Temperature Specifications (without Optional Heater): -20°C to 60°C (-4°F to 140°F)
*LiftMaster recommends professional installation and only supports products that are being installed or serviced by a professional installer. For installations that are purchased on Gatecrafters.com we can support installation, general troubleshooting, and warranty assistance directly.
