Instant Price Match: Purchase from an authorized dealer of LiftMaster to ensure your warranty is valid! Every Authorized LiftMaster dealer must advertise at their minimum advertised price (MAP). You will always see the minimum advertised price on our site, however we shop our competitors daily. When you click the “instant price match” button above or call (813) 792-9726 we will give you today’s price, with shipping included.
The LiftMaster Elite SL3000UL Single Swing Gate Operator is designed for heavy traffic and is suitable for applications such as large gated communities, residential developments, commercial complexes, and private estates.
- Gate Materials: Wood, Steel, Aluminum, Vinyl, Chain Link, and others
- Max Gate Weight:
• Model SL3000501UL 1/2 HP: 1,000 lbs. (453.6 kg)
• Model SL3000101UL 1 HP: 2,000 lbs. (907.2 kg)
- Operating Temperature: -20°C to 60°C (-4°F to 140°F)
- Mounting Options: Mounted on a concrete pad/post mounting plate (not included)
- Push to Open: No
- Solar Compatible: No
- Power:
• Model SL3000501UL 1/2 HP: 120 Vac, 6 Amps (12 Amps including accessory outlets)
• Model SL3000101UL 1 HP: 120 Vac, 12 Amps (18 Amps including accessory outlets) - Power Wire Specification: 10, 12, 14 Gauge Wire (sold separately).
- Warranty: LiftMaster 7 Year residential, 5 Year Commercial Limited Warranty
Gate Crafters offers more expert assistance than anyone.
If you need help deciding if this gate opener has the abilities that are right for your gate we have live application specialists available 9am - 9 pm EST 7 days a week or try our exclusive gate opener recommendation tool 24 hours/day.
LiftMaster Elite SL3000UL High Traffic Single Swing Commercial Gate Operator Kit The SL3000UL opener is designed for professional installation only. Due to the nature of the 120VAC power, it is essential to have a trained professional, such as a certified electrician, install the gate opener. Gate Crafters does not consider the Elite series to be a DIY product.
 LiftMaster's Elite Series Commercial Slide Gate Operator carries the Good Housekeeping Seal and comes with a 2 year Good Housekeeping warranty. You can choose between 1/2 HP or 1 HP models from the options menu above.
The LiftMaster Elite SL3000UL model is the top choice for heavy-traffic applications and high-demand customers, including large development and management companies, prestigious residential gated communities, and custom home builders. The #41 chain is guided by two slotted UHMW rollers, which prevent the chain from slipping off the drive sprocket, reducing the need for maintenance. The SL Series uses a solid steel, machined pulley and a notched V-groove belt for highly efficient torque transfer from the motor to the gear reducer. The 1/2 HP, instant-reversing parking gate motor utilizes high-speed ball bearings for smooth and quiet operation. Additionally, the highly efficient, extremely quiet 30:1 worm gear reducer ensures reliable performance. Featuring the highest-quality components and backed by years of proven reliability, each unit is meticulously inspected and mechanically tested to deliver exceptional performance. Unique engineering innovations ensure that any LiftMaster Elite SL3000UL model will meet the needs of nearly every type of high-traffic gated entrance. All of this is supported by the safety and reliability of the most advanced control board in the industry. Furthermore, the LiftMaster Elite complies with the high safety standards of the UL 325 listing, making it a reliable and safe gate opening device. Each LiftMaster sliding gate opener comes with a wired edge kit for safety during the opening and closing of your gate. For customers who prefer to keep wires hidden, we suggest the LiftMaster Safety Monitored Wireless Edge Kit.
Gate Crafters has the resources you need.
How do you use your gate opener system once you get it? Gate Crafters is the only retailer to give a real answer to this question. We have develop videos for installing many of our gate openers and products and write DIY focused manuals for most gate openers and have individual instructions for each accessory to be installed with each gate opener.
|
Reliable - Legacy elite heavy-duty commercial gear-driven transmission provides unsurpassed reliability.
- Limit switch design provides precision limit accuracy and reliability.
- Surge suppression provides industrial surge and lightning protection against strikes up to 50 feet away.
- Warranty: 5 years commercial, 7 years residential.
Smart - myQ® Technology enables you to securely control and monitor your gate operator from anywhere.
- Wireless dual-gate communication synchronizes gate opening/ closing and eliminates expensive driveway trenching costs.
Safe and Secure - Security+ 2.0® safeguards access to property with an encrypted signal to offer extended range with Security+2.0.
- Inherent reversing sensor detects obstructions and reverses gate when closing or stops/reverses the gate when opening.
- Pre-motion warning alarm activates on-board alarm 3 seconds prior to gate motion.
- Manual disconnect when unlocked allows gate to be operated manually.
- Quick close and anti-tailgate quickly secure property, preventing unauthorized access.
- UL® Listed Gate operators with monitored safety entrapment protection devices.
Included Accessories: - LMRRUL Monitored Retro Reflective Photo Eye enhanced retro-reflective photo eye now with heater and wider polarized beam, engineered to stay aligned; max. Range: 50 ft.
- Monitored Small Profile resistive edge pressure-sensitive edge stops and/or reverses gate when obstructed.
Mechanics - Continuous-Duty Motor with Class H Insulation is rated for high-cycle, high-temperature applications (available in 1/2 and 1 HP)
- Operator Duty Rating: Continuous Duty
- Wormgear Reduction: Commercial oil-bath gearbox providing 30:1 Wormgear Reduction
- Chain: #41 Black Oxide (25ft. Supplied)
Power - 115V Single-Phase
- Accessory Power: 24VDC 500mA output
- 2 Auxiliary Outlets
- Optional Kit (3PHCONV) to convert an input voltage of 208/240/480/575VAC to an output Voltage of 115VAC
Commercial-Grade Design - Chassis: constructed with 1/4 in. gold zinc-plated steel for rust prevention
- Cover: High-Density, UV-Resistant , 1-Piece Polyethylene plastic for excellent heat and corrosion resistance
- UL® Usage Classification: I, II, III and IV
- Operator weight: 140 lbs.
Dimensions - Height: 26.51”
- Width: 18.14”
- Depth: 20.39”
Temperature Specifications - Without heater: -4°F (-20°C ) to 140°F (60°C
- With optional heater: (HTRNB) -40°F (-40°C ) to 140°F (60°C)
Gate Travel Speed Standard Features - External Alarm Reset Button instantly resets the built in safety alarm siren
- Mechanical Limit System maintains accurate gate position throughout gate travel, even after using manual disconnect
- Monitored Safety Inputs 3 main board, 3 expansion boards
- Security+ 2.0® On-Board Radio Receiver up to 50 remote controls (unlimited with 811LM/813LM).
- Led Diagnostic Display simplifies installation and troubleshooting
- Programmable Auxiliary Relays make adding additional features easy
HomeLink® Compatible - Compatibility Bridge™ (not included) necessary for certain vehicles. Visit bridge.liftmaster.com to find out if a Bridge is needed.
- HomeLink® is a registered trademark of Gentex Corporation.
.jpg)
- Pad Mount Gate Operator
- Control Board
- Photo Eye
- Edge Sensor
|
- (2) Free LiftMaster Remotes
- (2) Keys
- Chain #41
|
- Instruction Manual
- (2) Warning Signs
- Eye Bolt Kit
|
 For over a decade, Gate Crafters has been the leading online retailer of gate openers and accessories. With our extensive technical and installation expertise, we proudly serve the DIY market. We believe that every customer deserves the chance to take pride in their projects, whether they are installing or troubleshooting their gate openers. Everyone should have access to high-quality products without the need of a professional. At Gate Crafters, we empower you to install with confidence by offering access to our trained technical staff seven days a week from 9 AM to 9 PM EST. By installing your gate opener system yourself, you can save thousands of dollars over its lifespan while gaining valuable knowledge about your installation and how the system operates. This understanding will not only make troubleshooting easier, but also enable you to perform routine maintenance with confidence in the future.
Gate Crafters is the DIY factor.
Gate Crafters further adds to most of our gate openers for easier DIY installation. We have developed exclusive components (example: easy adjustable mounting brackets), customized instructions, and offer a full spectrum of accessories to truly cover all aspects of the installation of your gate opener. In addition we have the largest staff of factory trained technicians in the US.
- Order specific customized accessory wiring instructions
- 360 degree accessories - we can take you through exit, entry, safety, power, and all other minute details to create a fully rounded kit.
- Free 24/7/365 Installation Support
- Free 7 day/week Technical Support
- Largest Number of Certified Techs in America
- Free assistance to find the right gate opener for your gate
- Free systems design assistance to match the right accessories to fit your needs.
- Extremely competitive pricing
- Free shipping on all accessories purchased with a gate opener
- We stock replacement parts
- Many brands of many types of accessories, enough to handle just about any operational situation you can imagine
Gate Crafters has actual experience.
We have a testing area, we have factory and internal training courses, we build gates and have our own gates that are automated, we attended all industry trade shows in multiple countries and are a member of the AFA, and we pay visits to our chosen manufacturers' factories. All these factors are what have lead to us having so many exclusive additions. When you see and actually use as many products as we have you tend to have many ideas for minor changes that have major impacts. We acted on these ideas and have utilized them to help thousands of customers automate their gates.
The following tools and supplies are suggested in the manufacturer manual for optimal installation. They are not provided by Gate Crafters, however, most tools are available at local hardware stores for purchase or rental.
- 1/2" wrench for cover screw 5/16"
- 3/4" wrench for 1/2" concrete anchors
- Screwdrivers (Philips head and flat head)
- Cable cutters and strippers
Please refer to the Installation Manual for Tools Needed. Depending on the type of gate, power supply and contributing environmental factors additional tools or supplies may be needed. Please review the product manual associated with this gate opener model for further details. |
LiftMaster Elite Opener (older model)
Send us your installation images! Please email them to customerphotos@gatecrafters.com |
Manual: LiftMaster SL3000UL Installation Manual
Manual: Elite CSW200UL / SL3000UL / SL3000UL Dual GateCrafters Timer
QB ID: SL3000UL - 1/2HP
|
|
