The Estate Swing E-S302 Classic features a design that has been in use for over 30 years. This is paired with advanced electronics that completely eliminates tricky programming. The
E-S302 Classic is "So smart it's simple."
- Gate Materials: Wood, Steel, Aluminum, Vinyl, Chain Link, and others.
- Weight and length: Up to 12' in length or 600 lbs
- Max degree of opening: 110 degrees
- Gate Post or Column size (pull to open): Max 4" x 4" post or gate mounted 2" from the rear face of a column.
- Push to Open: Yes, no additional bracket needed - setback above does not apply to push to open.
- Solar Compatible: No - must be within 200 feet of outlet
- Power: Low Voltage Transformer (included) and Backup Batteries (Optional, Not included)
- Power Wire Specification: 16 gauge wire (purchased separately). Length is determined by distance between transformer power supply and the control box.
- Operating Temperature: -20 to 130 F
- On Special: Save $20 on the GateCrafters MyQ receiver when you purchase an Estate Swing gate opener!
Purchase this Estate Swing gate opener and the GateCrafters.com MyQ Receiver kit to open your gate via cell phone app and receive a $20 discount.
- Warranty:1-year electrical/ 5-year component limited warranty. (Click Here for Warranty Pros and Cons)
|
|
|
|
|
GateCrafters.com offers more expert assistance than anyone. If you need help deciding if this gate opener has the abilities that are right for your gate we have live application
specialists available 9am - 9 pm EST 7 days a week or try our exclusive gate opener recommendation tool 24 hours/day.
|
|
|
|
|
|
Estate Swing Gate Openers are made for the DIY gate opener customers. With easy bolt on brackets and simple setback templates, Estate Swing has made it easy for any homeowner to install their gate opener and automate their gate. Estate Swing gate openers can be installed with simple household tools and do not require any special expertise or building code approval*. Gate Crafters has been aiding customers for over a decade in providing technical and installation support 7 days a week from 9 am to 9 pm, EST and is the premier source for Estate Swing opener and accessories because of this experience.
When you DIY install your gate opener system, you will save $1000s of dollars over the life of your gate opener. You will have working knowledge of your gate opener installation and how the gate opener works. This will make it easier for you to troubleshoot your system and perform routine maintenance, if needed in the future.
*Disclaimer:We are currently unaware of any required building code inspections required for any installation of an Estate Swing gate opener(s). Moreover, we cannot guarantee all counties would not require approval.
|
|
|
|
|
|
GateCrafters.com offers more expert assistance than anyone. If you need help troubleshooting or installation support with your gate opener,we have live technical support specialists available 9am - 9 pm EST 7 days a week or try our exclusive gate opener recommendation tool 24 hours/day.
|
|
|
|
|
|
|
Estate Swing gate openers are designed to be easy to install for the average handyman. Every unit comes standard with everything needed to automate your gate, including mounting
brackets (hardware to affix brackets to the gate and column are not included). The Classic series of Estate Swing have a few features that are made for DIY installers. First it is has no
learning procedure like all other openers. Because of its smart usage it runs from one limit to the other without having to learn the procedure to the processor. Some times simpler is better!
The magnetic limit switches are adjustable on the bottom of the arm; simply slide them to where you need them. Third, it has fully adjustable brackets that can be made to fit any situations
including push to open. Installers have alternate parts for gate openers on hand; homeowners do not; that is why these brackets are designed to fit all needs.
Also included is Estate Swings unique user directed instruction manual. Estate Swing, being closely involved with its customers, has created the first user driven updateable manual for
continuous improvement of installation ease, maintenance and trouble shooting updates. Gate Crafters also brings DIY projects to a new level of simplicity with our 7-day/week technical
support and 24/7/365 scheduled installation support.
All Estate Swings are built to the highest standards world wide. Each unit is put through rigorous quality control testing on each component. The Estate Swing E-S302 meets and
exceeds UL325 standards for anti-crushing safety.
The Estate Swing E-S302 Dual Opener is a low voltage system, eliminating the need to run 110 AC to your gate. Simply run low voltage wire to a household outlet within 200' of the
operator or use the battery board alternative up to 1000 feet (Buy battery board alternative at the same time as this opener and save $200 instantly). This is a Constant Duty DIY gate opener. What does this mean to you? These gate openers will run again and again without running a battery down. All other DIY gate
openers run off of a battery and are trickle charged after a cycle is run to recharge that battery. If cycles are run off the battery faster than the power can charge it, then your gate opener
runs the risk of being temporarily stuck closed. With the E-S302 Classic the power for the cycles comes directly from the 24V transformer plugged into a standard outlet; the batteries
(not included and optional) are strictly backup for power outages. Thus add another level of reliability and peace of mind.
The Estate Swing E-S302 Dual Opener has features never before seen or new to economically priced openers.
About the Classic Series
The Estate Swing Classic Series is: "So smart, it's simple." This collection of openers has a classic design with unsurpassed reliability. It's a design that has been in use for over 30 years but paired with advanced electronics that completely eliminates tricky programming.
|
|
|
|
|
|
GateCrafters.com is the DIY factor. GateCrafters.com further adds to most of our gate openers for easier DIY installation. We have developed exclusive components (example:
easy adjustable mounting brackets), customized instructions, and offer a full spectrum of accessories to truly cover all aspects of the installation of your gate opener. In addition we have
the largest staff of factory trained technicians in the US.
|
|
|
|
|
|
- NO Learning Procedure This is one of the most desirable features of this intelligent control board. Once everything is wired in you can just run your gate opener. All other
openers have to go through a learning procedure to know how long to run for and other details. No hassles here.
- Time Tested Design The Classic series of the Estate Swing is the identical design of the first electro-mechanical gate opener. This design has been used for over 30 years and
is still in use on thousands of homes and businesses around the globe. This is the design that started it all and made people confident that electro-mechanical could be more reliable,
efficient and cost effective than hydraulic gate openers.
- Easy Access Adjustable Magnetic Limit Switches There are many pluses to the limit switches on this unit. They are easy to adjust and access. They are on the bottom of the
exterior of the arm, simply slide them to the location needed and tighten down a screw. Secondly, both the open and closed point is adjustable; this gives you more flexibility of stopping
points after the brackets are bolted into place. Lastly they are magnetic so there are no components to wear out or break from contact.
- Adjustable Run Time/Soft Stop One of the parameters you can designate for this opener is a run time. The advantage of this is, again, it is not a learned procedure, but
something you input manually as an adjustment for your soft stop. The purpose is to give an option for where you want soft stop to begin. If you make the run time the same as the actual
run time from limit to limit it will slow down half way; as you extend the run time past that time the soft stop will become shorter and give you a faster opening time. The board makes it
easy to set, it has a counter on it telling you how many seconds it takes to go from open to close - then you simply put that number or a number of your choosing to delay the slow
down.
- EZ read digital display notifications: The display will indicate when it is sending poser to the electric lock, when it is open, when it is in auto-reclose pause countdown, when it is closing and visually counting the run time. All this info makes it easy for the Do-It-Yourselfer to understand their gate opener clearer and look like a master installer.
- Closed position lock release: The Estate Swing classic is the ONLY gate opener on the market to release your solenoid gate lock for a second time after the closed limit is reached. Why is this a plus? It shows true appreciation for customer feedback. For years the number one complaint from customers is the solenoid gate locks take too much force to lock back into place. And with the advent of soft stop this has become even more of an issue. The Estate Swing classic send a 1 second burst of power to the lock to allow the lock to re-latch electronically rather than through force.
- Obstruction sensing alarm: Safety has always been the top priority for Estate Swing. The classic now comes with an alarm to let you know when a problem has occurred. If the gate makes contact with an obstacle it will stop and back up for 3 second to clear the obstacle. If the gate is jammed on the obstacle making an obstruction happen 3 times in a row the system will shut down and an alarm will sound until the system is reset notifying anyone around the gate that there is a problem needing immediate attention.
- Large 24V Motor - The motor of the E-S302 is one of the largest found on any residential gate opener. It is well equipped to handle gates up to 600 lbs, more weight then
found in many heavily ornamented gates.
- Easily Adjustable Brackets - The brackets are set up to be user customized to fit any need configuration; push to open, pull to open, mounting on back of post, mounting on
side of post, etc.
- Large Opening Arch Capabilities - The E-S302 has the ability to open gates up to 110 degrees, well beyond most other openers.
- Advanced Gear System - The gear system is one of the most important parts of a gate opener; it influences power, control, reliability, and the life span of the motor. The
E-S302 uses an advanced worm gear system cutting down on bearing wear and motor deterioration.
- All Weather Compatible - This arm can handle the cold, heat and everything in between.
- Highest Level of Safety The Estate Swing E-S302 automatically reverses directions when it comes in contact with an obstruction. The Estate Swing E-S300 also has the
safest method of controlling safety devices. All safety devices are set up on a Normally Closed circuit. Some gate openers are set up on a normally open circuit. What this means is that the
Estate Swing E-S302 is virtually fail-safe. If a safety device does not activate for any reason the Estate Swing E-S302 will not operate, keeping your loved ones and assets safe. Gate
openers with safety devices set up on a Normally Open connection will operate with the disabled safety device and the consumer will not know the safety device is inactive until it is too
late!
- Quick, Safe and Secure Manual Release Every unit comes with a key chain ready manual release key. In the rare case power has failed and the back up battery is not
charged, the manual release key can be used to safely open your gate without damaging your opener arm or disconnecting anything from your gate.
- Adjustable Performance Features Adjust the performance of your gate opener to fit your tastes, lifestyle and needs. You can adjust Pause Times, Opening/Closing Delays,
Static Force, etc.
- 24 Volt Output Terminals Convenient for accessories requiring power. i.e. locks, sensors, etc.
- Long Range Radio Receiver - Powerful 433 mhz. One of the4 longest range transmitters on the market.
|
|
|
|
|
|
GateCrafters.com has the resources you need. How do you use your gate opener system once you get it? GateCrafters.com is the only retailer to give a real answer to this
question. We have develop videos for installing many of our gate openers and products and write DIY focused manuals for most gate openers and have individual instructions for each
accessory to be installed with each gate opener.
|
|
|
|
|
|
|
|
Included with Gate Opener from Manufacturer
|
Top of Page
|
|
Control Box
2 Operator Arms with power cable
Control Board
Manual Release Key
Low Voltage Transformer
433Mhz Receiver
433Mhz Transmitter
Adjustable, bolt on mounting brackets
Mounting Hardware
Instruction Manual, Public Warning Sign, Quick Check color wiring diagram and setback cutout
Order specific customized accessory wiring instructions
|
Graphics from Manual:
(Note: These are the parts for the Single Swing. The Dual will have two operator arms)
 |
|
Gate Crafters.com Exclusive Product & DIY Additions
|
Top of Page
|
|
Additional Transmitter
360 degree accessories - we can take you through exit, entry, safety, power, and all other minute details to create a fully rounded kit.
Free 24/7/365 Installation Support
Limited 5 year mechanical warranty on ALL Estate Swing openers.
Limited 1 year electrical warranty
Free 7 day/week Technical Support
Largest Number of Certified Techs in America
Free assistance to find the right gate opener for your gate
Free systems design assistance to match the right accessories to fit your needs.
Extremely competitive pricing
Free shipping on all accessories purchased with a gate opener
We stock all replacement parts
Many brands of many types of accessories, enough to handle just about any operational situation you can imagine
|
|
|
|
|
|
GateCrafters.com has actual experience. We have a testing area, we have factory and internal training courses, we build gates and have our own gates that are automated, we
attended all industry trade shows in multiple countries and are a member of the AFA, and we pay visits to our chosen manufacturers' factories. All these factors are what have lead to us
having so many exclusive additions. When you see and actually use as many products as we have you tend to have many ideas for minor changes that have major impacts. We acted on
these ideas and have utilized them to help thousands of customers automate their gates.
|
|
|
|
|
|
|
|
The following tools and supplies are suggested in the manufacturer manual for optimal installation. They are not provided by GateCrafters, however, most tools are available at local
hardware stores for purchase or rental.
- Power Drill
- Crescent Wrench
- Flat Head Screwdriver
- Hacksaw
- Phillips Head Screwdriver
- C-Ring Pliers
- Tape Measure
- Level
- Wire Strippers
- C-Clamps
- 3/8", 1/4", 5/16" Drill Bits
Depending on the type of gate, power supply and contributing environmental factors additional tools or supplies may be needed. Please review the product manual associated with this gate opener model for further details.
|
|
Words from Senior Application Engineer, Anthony Gaeto
|
Top of Page
|
"The Estate Swing Classic series is one of the best things I have seen come to the gate opener market in a while. It combines an advanced yet simplified electronics board with tried and
true mechanical technology. In an era of adding bells and whistles to everything sometimes it is better to have something that just plain works and in a way that even the untrained installer
can understand. A real plus for the Do-It-Yourself market.
The Classic series gate openers are linear actuators reflecting 30 years of gate opener in-use reliability. The design of the Estate Swing Classic opener arm is the design that launched
electro-mechanical gate openers. In the early days of gate opener automation, the thought was if you were going to do a piston style gate opener you had to use hydraulics; however low
voltage motors and gear driven system are far more efficient and maintenance free. This is the design that made the transformation and the design was so solid it has lasted for 30 years and
is still being used today.
The magnetic limit switches make a big difference in the longevity of this design. Magnetic limit switches have no parts that make contact; eliminating the possibility of a part wearing down
over time. The adjustment can be done on both the open and closed side. Many gate openers simply are adjustable on one side or the other but if you want to make adjustments on the
permanent side you would have to re mount the brackets. The adjustment is also the easiest I have seen. Most require turning some type of screw and guessing on the hidden limits
position and degree of movement. These you simply slide them along the bottom of the arm and tighten a screw when you are set. You will be able to see how much you are moving the
limit in adjustment.
The intelligent control board is the best DIY aspect of this opener. The high tech part of it is all in the back end of how it regulates power, senses obstructions, etc. The user end is
simplicity at its best. There is no learning process so this means you can just hook up all the wires, press your remote and it will begin running. Some adjustments to the limit placement and
some of the parameters will probably need adjustment, but at least it will be a running gate opener with no confusing programming steps to begin.
Safety is always a top concern with Estate Swing. They have designed their system to be the safest in the world. We at GateCrafters.com always recommend having external safety
devices such as photo sensors installed on your opener to prevent damage or injury. The Estate Swing Classic series, first, has an auto-stop feature built in. Even if you do not decide to
install any external safety devices, the Estate Swing E-S 302 will automatically stop if it comes in contact with an obstruction. The top safety feature is how safety devices are wired on the
Estate Swing Classic. Other gate openers have a flawed system; they are hooked up on a normally open circuit, which means if your safety device is not functioning properly it will not stop
the movement of your gate. This can lead to disastrous results. The Estate Swing Classic works on normally closed connections for safety devices. In most cases, if the safety device is not
functioning properly, the normally closed connection will be open, the same as when there is a breach of the safety device, and the gate will not move.
GateCrafters.com was selected as a Estate Swing partner because our profound commitment to customer service. Every member of our technical support staff has had direct training from
the manufacturer. We are available 7 days a week for support, even during holidays, from 9 A.M to 9 P.M. Eastern Time. Also we will make ourselves available to you after hours upon
request for installation questions absolutely free 24 hours a day. I believe every customer will find the support they need at GateCrafters.com and that is what has lead us to be the number
one seller of gate openers in the world.
I stand behind the values of GateCrafters.com and would like to invite you to give us a try. You will find the service, knowledge and enthusiasm can't be beat; and the price will amaze you
as well."
|
|
Estate Swing Classic Factory visit October 2010
|
Top of Page
|
|
Innovation and quality are the hallmarks of the “Classic” line of gate openers. This line is known for innovations that really matter. Yes, it is true that some if the new openers look sleeker or have better aesthetic designs but the folks that manufacture the classic focus on something much deeper. Currently the classic swing operators are the only openers on the market that have solved the soft close locking issue with their true lock system. It is this type of innovation that keeps this line in front of the pack for meaningful innovations.
This design is 40+ years old, it has survived because it “just works” its super simple and reliable worm drive gear reduction, sealed ball bearings and acme screw combination leaves very little to go wrong, giving the Estate Swing Classic one of the longest life expectancies in the industry. The Classics’ innovative fully sealed magnetic limit switches are the perfect pair, adding even more to their reputation of quality.
The focus on life expectancy and cross compatibility has been great, we have been through a half dozen board upgrades that all match with the same opener arms. This allows for customers to enjoy the latest innovations in the industry, easily added to their existing operator arms. We meet with factory reps face to face at least twice a year, when we meet they are constantly probing us for what quality issues may have crept up and how customer demands are changing. I say the word “classic” stands for the way that this manufacturer treats its customers, the classic way we all want to be treated.
|
| Click Images Below to View Larger and Learn More |
|
Product Images - Click to Enlarge
|
Measuring for Driveway Gate Set Back
How to Trench Your Driveway to Install Wires
Control Board Overview
Installing Mounting Brackets
Easy Limit Adjustment
